■主要技术特性 MAJOR TECHNICAL CHARACTERISTICS
     温度范围 Temperature Range                     -55~+155℃(PE Cable -40~+85℃)
     振    动 Vibration                                         100m/S2(10~500Hz),10g
    特性阻抗  Impedance                                   50Ω
    频频范围  Frequency Range                      DC~11GHz
   工作电压  Working Voltage                      1000V r.m.s    at sea level
   耐    压  Withstanding Voltage                    2500V r.m.s    at sea level
   接触电阻  Contact Resistance
              内导体之间 Center Contact             ≤1mΩ
              外导体之间 Outer Contact              ≤1mΩ
 绝缘电阻  Insulation  Resistance                    ≥5000MΩ
 内导体保持力  Center conductor retention force       ≥0.56N
 连接螺套保持力  Coupling nut retention force         450N
 插入损耗    Insertion Loss                          ≤0.24dB/6GHz
 电压驻波比  Voltage Standing Wave Ratio
                直式  Straight                ≤1.15/6GHz
             弯式  Right angle            ≤1.25/6GHz
 耐用性  Durability(mating)                         ≥500次（cycles）
■材料涂覆  MATERIAL ＆ PLATING
      壳体  body                  黄铜  brass                            镀亮镍  nickel plated
      插针  pin contact           黄铜  brass                            镀硬金  gold plated
   插孔  socket contact          镀青铜或锡青铜beryllium or tin bronze   镀硬金  gold plated
   弹性接触件 resilient contact   镀青铜 beryllium-copper                镀硬金  gold plated
   绝缘体 insulator            聚四氟乙烯 PTEE
   压接套 crimp ferrule        铜合金 copper alloy      镀镍或镀金 nickel or gold plated
   o型密封件 o-ring sealing     硅橡胶 6146 silicone rubber
■适用技术标准  APPLICABLE STANDARD
 MIL-C-39012
 CECC 22210
 IEC-60169-15
